Hydro-Cure cartridges use depth filtration with a gradient density design to trap particles of varying sizes and maximize lifespan. Made from 100% pure polypropylene resin, they are suitable for various process fluids due to their chemical compatibility. GAC versions utilize activated carbon for taste and odor issues. They offer high flow rates with minimal pressure drop and are designed to fit most standard filter housings. The filters are certified under NSF/ANSI Standard 42 for material requirements.
Material :
100% Polypropylene fibers or Granular Activated Carbon (GAC)
Filtration Rating:
Nominal; available in various micron ratings and dual gradient options.
Standard Lengths:
9 7/8″ (10″), 20″, 30″, and 40″
Standard Diameters:
2.5″ and 4.5″ (for Big Blue® housings)
Max Operating Temp:
100°F (38°C) to 125°F (52°C), depending on model
Recommended Flow:
Up to 5 gpm per 10″ length (not to exceed 10 gpm per 10″ length for optimal efficiency)
Contaminant Removal:
Sand, silt, dirt, rust particles (sediment filters); chlorine, bad taste, and odor (GAC filters)
Hydro-Cure Clack Cartridge Filters – 40″ length x 1 micron
